TECHNICAL DATA 22
145
Nut, foot brake lever stop M8 20 Nm (14.8 lbf ft)
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Nut, rim lock M8 12 Nm (8.9 lbf ft)
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 25 Nm (18.4 lbf ft)
Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft)
Screw, chain sliding piece M8 15 Nm (11.1 lbf ft)
Screw, engine brace on engine M8x20 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, engine brace on frame M8x15 25 Nm (18.4 lbf ft)
Loctite
®
2701™
Screw, engine sprocket cover M8 15 Nm (11.1 lbf ft)
Screw, fork stub M8 15 Nm (11.1 lbf ft)
Screw, front brake caliper M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft)
Screw, manifold on cylinder head
brace
M8 15 Nm (11.1 lbf ft)
Screw, side stand attachment
(XC‑F US)
M8 33 Nm (24.3 lbf ft)
Loctite
®
2701™
Screw, subframe bottom M8 30 Nm (22.1 lbf ft)
Loctite
®
2701™
Screw, subframe top M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Screw, top steering stem M8 20 Nm (14.8 lbf ft)
Loctite
®
243™
Screw, top triple clamp M8 17 Nm (12.5 lbf ft)
Engine carrying screw M10 60 Nm (44.3 lbf ft)
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft)
Remaining screws, chassis M10 45 Nm (33.2 lbf ft)
Screw, bottom shock absorber M10 60 Nm (44.3 lbf ft)
Loctite
®
2701™
Screw, handlebar support M10 40 Nm (29.5 lbf ft)
Loctite
®
243™
Screw, top shock absorber M10 60 Nm (44.3 lbf ft)
Loctite
®
2701™
Nut, fuel pump M12 15 Nm (11.1 lbf ft)
Nut, angle lever to link fork M14x1.5 60 Nm (44.3 lbf ft)
Nut, frame on linkage lever M14x1.5 60 Nm (44.3 lbf ft)
Nut, linkage lever on angle lever M14x1.5 60 Nm (44.3 lbf ft)
Nut, fork pivot M16x1.5 100 Nm (73.8 lbf ft)
Screw, front wheel spindle M20x1.5 35 Nm (25.8 lbf ft)
Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft)
Screw-in fitting, cooling system M24x1.5 18 Nm (13.3 lbf ft)
Loctite
®
243™
Nut, rear wheel spindle M25x1.5 80 Nm (59 lbf ft)
