KTM 300 XC-W TPI 2019 User Manual

SERVICE WORK ON THE CHASSIS 12
81
12.22 Removing the air filter box cover
E00873-10
Condition
The air filter box cover is secured.
–
Remove screw
1
.
E00873-12
–
Pull off the air filter box cover in area
A
sideways and take
off toward the front.
12.23 Installing the air filter box cover
E00873-11
–
Insert the air filter box cover in the area
A
and clip it into the
area
B
.
E00873-10
Condition
The air filter box cover is secured.
–
Mount and tighten screw
1
.
Guideline
Screw, air filter box
cover
EJOT PT
®
K60x20-Z
3 Nm (2.2 lbf ft)

KTM 300 XC-W TPI 2019 Specifications

General

Displacement	293.2 cc
Bore x Stroke	72 mm x 72 mm
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Seat Height	960 mm
Ground Clearance	370 mm
Engine Type	2-stroke
Fuel System	TPI (Transfer Port Injection)
Front Suspension	WP XPlor 48
Rear Suspension	WP XPlor PDS
Front Brake	260 mm disc
Rear Brake	220 mm disc
Fuel Capacity	9 liters
Frame	Central-tube frame with double-cradle
