TECHNICAL DATA 22
139
Nut, inner clutch hub M18x1.5 100 Nm (73.8 lbf ft)
Loctite
®
243™
Nut, primary gear wheel M18LHx1.5 120 Nm (88.5 lbf ft)
Loctite
®
243™
Screw plug, oil screen M20x1.5 15 Nm (11.1 lbf ft)
Plug, timing chain tensioner M24x1.5 40 Nm (29.5 lbf ft)
Screw, alternator cover M24x1.5 18 Nm (13.3 lbf ft)
Fixing nut for main bearing inner
ring
M27x1 60 Nm (44.3 lbf ft)
Loctite
®
243™
22.3 Capacities
22.3.1 Engine oil
Engine oil 1.0 l (1.1 qt.) Engine oil (SAE 10W/50)
( p. 147)
22.3.2 Coolant
Coolant 0.95 l (1 qt.) Coolant ( p. 147)
22.3.3 Fuel
Total fuel tank capacity, approx. (All SX‑F models)
Super unleaded (ROZ 95) ( p. 148) 7 l (1.8 US gal)
Total fuel tank capacity, approx. (All XC‑F models)
Super unleaded (ROZ 95) ( p. 148) 8.5 l (2.25 US gal)
Fuel reserve, approx. (All XC‑F models) 1.5 l (1.6 qt.)
22.4 Chassis
Frame Central tube frame made of chrome molybdenum steel
tubing
Fork WP XACT 5448
Suspension travel
front 310 mm (12.2 in)
rear 300 mm (11.81 in)
Fork offset 22 mm (0.87 in)
Shock absorber WP XACT 5750
Brake system Disc brakes, floating brake calipers
Brake discs - diameter
front 260 mm (10.24 in)
rear 220 mm (8.66 in)
Brake discs - wear limit
front 2.5 mm (0.098 in)
rear 3.5 mm (0.138 in)
Offroad tire pressure
front 1.0 bar (15 psi)
rear 1.0 bar (15 psi)
