KTM 390 DUKE 2017 User Manual

9 RIDING INSTRUCTIONS
101
Warning
Danger of accidents Higher total weight increases the stopping distance.
– Take the longer stopping distance into account when carrying a passenger or luggage with you.
Warning
Danger of accidents Salt on the roads impairs the brake system.
– Brake carefully several times to remove salt from the brake linings and the brake discs.
Warning
Danger of accidents ABS may increase the stopping distance in certain situations.
– Adjust application of the brakes to the respective riding situation and riding surface conditions.
Warning
Danger of accidents Excessively forceful application of the brakes blocks the wheels.
The ABS effectiveness is only ensured if it is switched on.
– Leave the ABS switched on in order to benefit from the protective effect.
– When braking, release the throttle and apply the front and rear brakes at the same time.
Info
When the ABS is enabled, you can achieve maximum braking power even on low grip surfaces such as
sandy, wet, or slippery terrain without locking of the wheels.

KTM 390 DUKE 2017 Specifications

General

Displacement	373.2 cc
Bore x Stroke	89 mm x 60 mm
Compression Ratio	12.6:1
Torque	37 Nm @ 7, 000 rpm
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling	Liquid cooled
Frame	Steel trellis frame, powder coated
Rear Suspension	WP monoshock
Front Tire	110/70 R17
Rear Tire	150/60 R17
Seat Height	830 mm
Ground Clearance	185 mm
Dry Weight	149 kg
Engine Type	Single cylinder, 4-stroke
Power	32 kW (44 hp) @ 9, 000 rpm
Clutch	Wet multi-disc clutch
Front Suspension	WP upside-down Ø 43 mm
Front Brake	320 mm Disc, Four-Piston Radial Fixed Caliper
Rear Brake	230 mm Disc, Single-Piston Floating Caliper
ABS	Bosch 9MB two-channel ABS
Fuel Tank Capacity	13.4 liters
