KTM 390 DUKE 2017 User Manual

15 ELECTRICAL SYSTEM
181
15.7 Changing the turn signal bulb
Note
Damage to reflector Grease on the reflector reduces the brightness.
Grease on the bulb will evaporate due to the heat and be deposited on the reflector.
– Clean and degrease the bulbs before mounting.
– Do not touch the bulbs with your bare hands.
K00017-10
– Remove the screw on the rear of the turn signal housing.
–
Carefully remove diffuser
1
.
–
Push bulb
2
lightly into the socket, turn approx. 30° coun-
terclockwise, and pull it out of the socket.
Info
Do not touch the reflector with your fingers and keep it
free from grease.
– Lightly push the new lamp into the socket and turn all the way
clockwise.
Turn signal (RY10W / socket BAU15s) ( p. 225)
– Check that the turn signal is functioning properly.
– Position the diffuser.

KTM 390 DUKE 2017 Specifications

General

Displacement	373.2 cc
Bore x Stroke	89 mm x 60 mm
Compression Ratio	12.6:1
Torque	37 Nm @ 7, 000 rpm
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling	Liquid cooled
Frame	Steel trellis frame, powder coated
Rear Suspension	WP monoshock
Front Tire	110/70 R17
Rear Tire	150/60 R17
Seat Height	830 mm
Ground Clearance	185 mm
Dry Weight	149 kg
Engine Type	Single cylinder, 4-stroke
Power	32 kW (44 hp) @ 9, 000 rpm
Clutch	Wet multi-disc clutch
Front Suspension	WP upside-down Ø 43 mm
Front Brake	320 mm Disc, Four-Piston Radial Fixed Caliper
Rear Brake	230 mm Disc, Single-Piston Floating Caliper
ABS	Bosch 9MB two-channel ABS
Fuel Tank Capacity	13.4 liters
