KTM 390 DUKE 2017 User Manual

7 COMBINATION INSTRUMENT
72
Fuel Range indicates the possible distance you can cover with the
fuel reserve.
Press and
hold the SET
button for 3-5
seconds.
All entries in the Trip 1 menu are reset.
7.17.11 Trip 2
F00808-01
– Press the SET button when the menu is closed.
– Press the UP or DOWN button until Info is marked. Press
the SET button to open the menu.
– Press the UP or DOWN button until Trip 2 is marked. Press
the SET button to open the menu.
Trip 2 shows the distance since the last reset, such as between two
refueling stops. Trip 2 is running and counts up to 9999.
ØCons2 indicates the average fuel consumption based on Trip 2.
ØSpeed2 indicates the average speed based on Trip 2
and Trip Time2.
Trip Time2 shows the journey time on the basis of Trip 2 and runs
as soon as a speed signal is received.
Fuel Range indicates the possible distance you can cover with the
fuel reserve.

KTM 390 DUKE 2017 Specifications

General

Displacement	373.2 cc
Bore x Stroke	89 mm x 60 mm
Compression Ratio	12.6:1
Torque	37 Nm @ 7, 000 rpm
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling	Liquid cooled
Frame	Steel trellis frame, powder coated
Rear Suspension	WP monoshock
Front Tire	110/70 R17
Rear Tire	150/60 R17
Seat Height	830 mm
Ground Clearance	185 mm
Dry Weight	149 kg
Engine Type	Single cylinder, 4-stroke
Power	32 kW (44 hp) @ 9, 000 rpm
Clutch	Wet multi-disc clutch
Front Suspension	WP upside-down Ø 43 mm
Front Brake	320 mm Disc, Four-Piston Radial Fixed Caliper
Rear Brake	230 mm Disc, Single-Piston Floating Caliper
ABS	Bosch 9MB two-channel ABS
Fuel Tank Capacity	13.4 liters
