22 TECHNICAL DATA
222
Screw, cylinder head M10 1st stage
30 Nm (22.1 lbf ft)
2nd stage
60 Nm (44.3 lbf ft)
Thread is oiled, head flat is greased
Screw, rotor M10 105 Nm (77.4 lbf ft)
Loctite
®
243™
Water temperature sensor M10 14 Nm (10.3 lbf ft)
Screw plug, cam lever axis M10x1 10 Nm (7.4 lbf ft)
Spark plug M12 15 Nm (11.1 lbf ft)
Nut, inner clutch hub M16LHx1.5 120 Nm (88.5 lbf ft)
Loctite
®
243™
Nut, primary gear/timing chain
sprocket
M16x1.5 120 Nm (88.5 lbf ft)
Loctite
®
243™
Oil screen screw plug, small M17x1.5 12 Nm (8.9 lbf ft)
Screw plug, alternator cover M18x1.5 10 Nm (7.4 lbf ft)
Oil drain plug M24x1.5 15 Nm (11.1 lbf ft)
Screw plug, alternator cover M24x1.5 10 Nm (7.4 lbf ft)

KTM 390 DUKE 2017 Specifications

General

Displacement	373.2 cc
Bore x Stroke	89 mm x 60 mm
Compression Ratio	12.6:1
Torque	37 Nm @ 7, 000 rpm
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling	Liquid cooled
Frame	Steel trellis frame, powder coated
Rear Suspension	WP monoshock
Front Tire	110/70 R17
Rear Tire	150/60 R17
Seat Height	830 mm
Ground Clearance	185 mm
Dry Weight	149 kg
Engine Type	Single cylinder, 4-stroke
Power	32 kW (44 hp) @ 9, 000 rpm
Clutch	Wet multi-disc clutch
Front Suspension	WP upside-down Ø 43 mm
Front Brake	320 mm Disc, Four-Piston Radial Fixed Caliper
Rear Brake	230 mm Disc, Single-Piston Floating Caliper
ABS	Bosch 9MB two-channel ABS
Fuel Tank Capacity	13.4 liters
