KTM 390 DUKE 2017 User Manual

22 TECHNICAL DATA
228
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw, ABS hose clamp M6 7 Nm (5.2 lbf ft)
Screw, ABS module M6 10 Nm (7.4 lbf ft)
Screw, ABS module retaining
bracket on frame
M6 7 Nm (5.2 lbf ft)
Screw, air filter box M6 6 Nm (4.4 lbf ft)
Screw, brake fluid reservoir of rear
brake
M6 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, brake hose clamp M6 7 Nm (5.2 lbf ft)
Screw, cable holder, side stand
switch
M6 9 Nm (6.6 lbf ft)
Loctite
®
243™
Screw, chain sliding guard M6 7 Nm (5.2 lbf ft)
Screw, combination instrument M6 7 Nm (5.2 lbf ft)
Screw, compensating tank M6 5 Nm (3.7 lbf ft)
Screw, damper block M6 8 Nm (5.9 lbf ft)
Screw, engine sprocket cover M6 8 Nm (5.9 lbf ft)
Screw, foot brake cylinder M6 9 Nm (6.6 lbf ft)
Loctite
®
243™
Screw, front fender M6 7 Nm (5.2 lbf ft)
Screw, front seat fixing M6 6 Nm (4.4 lbf ft)
Screw, front spoiler front M6x13 9 Nm (6.6 lbf ft)
Screw, front spoiler rear M6x9 9 Nm (6.6 lbf ft)

KTM 390 DUKE 2017 Specifications

General

Displacement	373.2 cc
Bore x Stroke	89 mm x 60 mm
Compression Ratio	12.6:1
Torque	37 Nm @ 7, 000 rpm
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling	Liquid cooled
Frame	Steel trellis frame, powder coated
Rear Suspension	WP monoshock
Front Tire	110/70 R17
Rear Tire	150/60 R17
Seat Height	830 mm
Ground Clearance	185 mm
Dry Weight	149 kg
Engine Type	Single cylinder, 4-stroke
Power	32 kW (44 hp) @ 9, 000 rpm
Clutch	Wet multi-disc clutch
Front Suspension	WP upside-down Ø 43 mm
Front Brake	320 mm Disc, Four-Piston Radial Fixed Caliper
Rear Brake	230 mm Disc, Single-Piston Floating Caliper
ABS	Bosch 9MB two-channel ABS
Fuel Tank Capacity	13.4 liters
