MAINTENANCE ON CHASSIS AND ENGINE 105
300265-10
– Check that sliding plate is seated correctly in the brake caliper support and insert
the brake linings.
Info
Make sure that decoupling plate is mounted on the piston side of the brake
pad.
100068-10
– Grease bearing bolt and insert the brake caliper with the bearing bolt into brake
caliper support .
Lubricant (T625) ( p. 180)
100069-10
– Swing the brake caliper downward. Mount and tighten the screw.
Guideline
Screw, rear brake caliper M6 10 Nm
(7.4 lbf ft)
Loctite
®
243™
– Operate the foot brake lever repeatedly until the brake linings lie on the brake disc and
there is a tight spot.
