MAINTENANCE ON CHASSIS AND ENGINE 118
– Close the cover of the fuse box.
– Install the front cover. ( p. 123)
9.60Ignition curve plug connection
301829-10
Plug-in connector is located under the trim at the front on the frame tube.
Possible states
• Performance – The plug-in connector is connected to achieve better performance.
• Soft – The plug-in connector is disconnected for better driveability.
9.61Changing the ignition curve
– Remove the front trim. ( p. 123)
Changing the ignition curve from Performance to Soft.
– Disconnect plug-in connector . (Figure 301829-10 p. 118)
Soft – The plug-in connector is disconnected for better driveability. ( p. 118)
Changing the ignition curve from Soft to Performance.
– Connect the plug-in connector . (Figure 301829-10 p. 118)
Performance – The plug-in connector is connected to achieve better performance. ( p. 118)
– Install the front trim. ( p. 125)
