MAINTENANCE ON CHASSIS AND ENGINE 109
Info
Proceed in the same way on the other wheels if necessary.
300278-10
– Position the wheel on the hub.
Info
Note the direction of travel of the front wheels.
Carefully position the wheel on the hub, being careful not to damage the threads
of the screws.
– Mount wheel nuts but do not tighten.
– Remove the vehicle from the work stand. ( p. 50)
– Pull the hand brake lever, push the locking pawl down and release the hand brake
lever. (Figure 301776-10 p. 20)
– Tighten the wheel nuts crosswise.
Guideline
Wheel nut M10x1.25 45 Nm
(33.2 lbf ft)
