7 COMBINATION INSTRUMENT
24
Info
The malfunction indicator lamp always lights up as long as the engine is not running. If the engine is run-
ning and the malfunction indicator lamp lights up, stop (taking care not to endanger yourself or other road
users in the process) and contact an authorized KTM workshop.
The oil pressure warning lamp always lights up as long as the engine is not running. If the engine is run-
ning and the oil pressure warning lamp lights up, stop immediately (taking care not to endanger yourself or
other road users in the process) and switch off the engine.
The ABS warning lamp and TC indicator lamp light up until a speed of approx. 6 km/h (approx. 4 mph) or
more has been reached.
Possible states
The turn signal indicator lamp flashes green simultaneously with the turn signal – The turn
signal is switched on.
Malfunction indicator lamp lights up yellow – The OBD has detected a malfunction in the
vehicle electronics. Come safely to a halt, and contact an authorized KTM workshop.
ABS warning lamp lights up yellow – Status or error messages relating to ABS.
TC indicator lamp lights up yellow – MTC ( p. 107) is not enabled or is currently interven-
ing. The TC indicator lamp also lights up if a malfunction is detected. Contact an authorized
KTM workshop. The TC indicator lamp flashes if MTC actively engages or if the Launch Control
( p. 52) is activated.
The idle indicator lamp lights up green – The transmission is in the neutral position.
The immobilizer indicator lamp lights up or flashes red – Status or error message of the alarm
system.
The oil pressure warning lamp lights up red – The oil pressure is too low. Stop immediately,
taking care not to endanger yourself or other road users in the process, and switch off the
engine.
The high beam indicator lamp lights up blue – The high beam is switched on.
The general warning lamp lights up yellow – A note/warning on operating safety has been
detected. This is also shown in the display.
