47CAB OPERATION
BOperation
C Heating
1. Set the mode lever to the or position.
2. Set the recirculation / fresh air selection lever to the
"FRESH AIR" position. To raise the temperature in the
CAB quickly, set this lever to the "RECIRCULATION"
position.
3. Adjust the blower (LO/ME/HI) switch and the
temperature control lever to achieve a comfortable
temperature level.
C Cooling or dehumidifying-heating
1. Set the mode lever to the position.
2. Rotate the front air outlet toward the chest area.
3. Set the recirculation / fresh air selection lever to the
"FRESH AIR" position. To reduce the temperature in
the CAB quickly, set this lever to the
"RECIRCULATION" position.
4. Press and turn on the air-conditioner switch with
indicator.
5. Turn on the blower (LO/ME/HI) switch.
6. Adjust the temperature control lever to the "COOL" or
an intermediate position to achieve a comfortable
temperature level.
A In summer when the heater is not used, keep the
temperature control lever at the "COOL" (leftmost)
position. Otherwise, hot air will raise the temperature
in the CAB.
(1) Mode lever
(2) Blower switch
(1) Front air outlet (A) "CHEST AREA"
(B) "FOOT AREA"
(C) "CLOSED"
(1) Mode lever
(2) Temperature control lever
(3) Blower switch
(4) Air conditioner switch with indicator light
