The jetting continues while the front wiper / washer
switch is pressed and the wiper is activated
continuously.
The front wiper / washer switch lights up when the
wiper is activated and washer liquid jets out too.
(1) Front wiper / washer switch (A) Wiper is activated
(B) Washer liquid jets out
IMPORTANT :
• Do not activate the wipers when the windows
are dry. Windows may be scratched.
Be sure to jet the washer liquid first and then
activate the wipers.
2. Washer fluid tank
When it is necessary, remove the white cap and fill
up the washer-fluid-tank. Use a fluid recommended by
your local Kubota dealer. Use a liquid which can stand
the frost.
(1) Washer fluid tank
(2) White cap
3. Precautions for using the wipers
in cold season
IMPORTANT :
• In the cold season, the wiper blades and
the wiper motor may become overloaded, and
cause damage. To avoid overloading of the
wiper blades and the wiper motor, be sure to
take the following precautions.
• While not in use during the cold season, keep the
wiper blades off the windscreen to prevent them
from being frozen to the windscreen.
• If the windscreen is covered with snow, scrape it off
the windscreen before using the wipers.
• If the wiper blades are frozen to the windscreen and
fail to move, be sure to turn the main key switch to
off and remove the ice from the blades. Then place
the main key switch back to on.
• When you use the wiper blades which is
commercially available in cold-season, make sure
that their size is the same as or smaller than that of
the standard ones.
HEATER
1. Airflow
Air in the CAB and fresh air introduced into the CAB
flows as shown in the following figures. Adjust the air
nozzles to obtain the desired condition.
(1) Air nozzle
(A) Driver area air
(B) Windscreen air
(C) Rear window air
2. Fan switch
1. Pressing the fan switch engages the fan of the
heating.
2. Pressing the fan switch a second time engages the
highest or second speed of the fan.
WIPER CAB OPERATION
