3SPECIFICATIONS
SPECIFICATIONS
SPECIFICATION TABLE
Model
M100GX M110GX M126GX M135GX
4WD
Engine
Model V3800-TI-CRS V6108-TI-CRS
Type
Common rail system, Direct Injection, with turbocharger,
water-cooled 4 cycle diesel
Number of cylinders 4
Total displacement cm 3769 6124
Bore and stroke mm 100 x 120 118 x 140
Rated revolution rpm 2600 2200
Low idling revolution rpm 800 to 850
Net power *1 kW (HP) 74.6 (100) 81.7 (109.5) 93.2 (125) 100.7 (135)
PTO power *1
(factory observed)
kW (HP) /
rpm
64.1 (86) /
2600
71.6 (96) /
2600
80.6 (108) /
2200
88.0 (118) /
2200
Battery capacity
12V, 100Ah at 20hours,
900CCA
12V, 160Ah at 20hours,
1090CCA
Fuel tank capacity L 190
Engine oil capacity L 10.5 14.6
Coolant capacity L 9.6 14.6
Dimensions
Overall length mm 4245 4400 4400 <4390>
Overall width
(minimum tread)
mm 2100 2130
Overall height mm 2810 2885
Wheel base mm 2435 2690 2690 <2680>
Tread
Front mm 1430/1530 1555/1655 1620 to 1740
Rear mm 1530 to 2035 1590 to 2085
Crop clearance mm 560 590 615
Weight kg 4100 4640 4640 <4840>
Traveling
system
Standard
tire size
Front tires 340/85R24 420/70R24
Rear tires 480/70R34 520/70R38
Clutch Multiple wet disc, Electronic Hydraulically operated
Steering Hydrostatic Power Steering
Braking system Hydraulically operated wet disk
Differential Bevel gears with differential lock (Front, Rear)
To Next Page
