Kubota M100GX User Manual

7IMPLEMENT LIMITATIONS
A Implement size may vary depending on soil operating conditions.
*1 Must remove front weight with this implement.
*2 Need subframe.
*3 The value contains the weight of KUBOTA standard bucket.
No. Implement Remarks
M100GX, M110GX M126GX, M135GX
4WD 4WD
1Slurry Tank
Max. Tank Capacity L 5000 6000
Max. Load Capacity kg 6000 7000
2 Trailer
Max. Load Capacity kg 7000 8000
Max. Drawbar Load kg 1500 1500
3Mower
Rotary-Cutter
Max. Cutting Width mm 3200 3200
Max. Weight kg 800 800
Flail Mower
(Heavy)
M a x . C u t t i n g W i d t h m m 4 2 6 7 4 2 6 7
Max. Weight kg 1360 1360
S i c k l e B a r M a x . C u t t i n g W i d t h m m 3 0 5 0 3 0 5 0
4 Sprayer
Max. Tank-
Capacity
Mid L 1000 1200
Rear 3P L 1200 1400
Drawbar L 5500 6000
5 Rotary Tiller
Max. Tilling Width mm 2700 2700
Max. Weight kg 1200 1200
6 Bottom Plow
Max. Size
14 in. x 5
18 in. x 4
20 in. x 3
22 in. x 2
24 in. x 1
14 in. x 6
18 in. x 5
20 in. x 4
22 in. x 2
24 in. x 1
Max. Weight kg 3P Type 1100 1100
7
Disk
harrow
3P Type
Max. Size 24 in. x 30 24 in. x 30
M a x . H a r r o w i n g W i d t h m m 3 6 0 0 3 6 0 0
Max. Weight kg 1000 1000
Drawbar Type Max. Harrowing Width mm 4570 4570
8Disc Plow
Max. Size 30 in. x 4 30 in. x 4
Max. Weight kg 1000 1000
9 Sub Soiler
Numbers of Cultivating Tines 3 3
Cultivating Depth mm 600 600
10 Cultivator
Max. Width mm 5490 5490
Number of Rows 6 6
Max. Weight kg 1000 1000
11 Front Blade *1,*2
Max. Cutting Width mm 2600 2600
Max. Oil Pressure MPa 18.1 18.1
12 Rear Blade
Max. Cutting Width mm 2600 2600
Max. Oil Pressure MPa 18.1 18.1
13 Front Loader *1,*2
Max. Lifting Capacity (Bucket
pivot pin, max. height) *3
kg 1950 2210
Max. Oil Pressure MPa 20.5 20.5
14 Box Blade
Max. Cutting Width mm 2430 2430
Max. Weight kg 800 800
15 Back Hoe *2
Max. Digging Depth mm 3050 3050
Max. Weight kg 1200 1200
16 Snow Blade
Max. Width mm 2600 2600
Max. Weight kg 800 800
