49OPERATING THE TRACTOR
7. If the switch is released and not operated for 4
seconds, a continuous buzzer sound occurs and the
setting is completed.
8. Follow the same procedure as for the (A) side to set
the speed for the switch (B) side.
A The set speeds will be stored even after the engine is
stopped.
C Canceling the setting
Any of the actions below will cancel the RPM dual memory
settings.
1. [Switch (A) side]
When the memory speed is engaged, press the switch
(A) again to cancel.
[Switch (B) side]
When the memory speed is engaged, press the switch
(B) again to cancel.
When the memory speed is canceled, the speed will
return to the speed that is determined by the hand
throttle lever (foot throttle).
(When the switch is pressed, the LCD will display the
engine speed that is in effect after memory speed is
canceled.)
2. Return the hand throttle lever to the lowest speed
position.
3. Turn the key switch to "OFF".
C Checking the speeds set in the memory
You can check the speed which is set for switch (A) and
(B) on the LCD by pressing the "Engine RPM dual
memory A/B indicator switch". (The display automatically
disappears after 1.5 seconds.)
A If the memory speed setting is set higher than the
value that was set with the Rev-limiter control dial, the
marks (1) and (2) shown in the figure below appear on
the LCD and the speed will not increase to the set
speed. (The Rev-limiter control dial takes priority.)
A For example if the speed set in the memory is 2000
rpm, and the Rev-limiter control dial is set to 1230 rpm,
then marks (1) and (2) shown in the figure below
appear on the LCD and the engine speed will not
increase above 1230 rpm.
(1) Engine RPM dual memory A/B indicator switch
(1) Lit or flashing
(2) [L] displayed
To Next Page
