G-6
ZD21N-EC, ZD21-EC, ZD28-EC, WSM
G GENERAL
• Use sandpaper to remove rust from terminals.
• Repair deformed terminal. Make certain there is no terminal
being exposed or displaced.
W1012346
• Make certain that there is no female connector being too open.
W1012430
[5] HANDLING OF CIRCUIT TESTER
• Use tester correctly following manual provided with tester.
• Check for polarity and range.
W1012684
(1) Exposed Terminal
(2) Bend Terminal
(3) Sandpaper
(4) Rust
(A) Correct (B) Incorrect
