G-17
ZD21N-EC, ZD21-EC, ZD28-EC, WSM
G GENERAL
[2] CHECK POINTS OF INITIAL 50 HOURS
Changing Engine Oil
CAUTION
• Be sure to stop the engine before changing oil.
1. Start and warm up the engine for approx. 5 minutes.
2. Place an oil pan underneath the engine.
3. To drain the used oil, remove the drain plug (1) at the bottom of
the engine and drain the oil completely.
4. Screw in the drain plug (1).
5. Fill new oil up to upper line on the dipstick (3).
IMPORTANT
• When using an oil of different manufacture or viscosity from
the previous one, remove all of the old oil.
• Never mix two different type of oil.
• Use the proper SAE engine oil according to ambient
temperatures.
Refer to “LUBRICANTS, FUEL AND COOLANT”.
(See page G-7.)
W1030749
Engine oil capacity
ZD21N
ZD21
3.5 L
3.7 U.S.qts.
3.1 Imp.qts.
ZD28
3.4 L
3.6 U.S.qts.
3.0 Imp.qts.
(1) Drain Plug
(2) Oil Inlet Plug
(3) Dipstick
(A) Upper Level
(B) Lower Level
