KYMCO DINK 125 User Manual

FUEL FILL CAP
To open the fuel fill cap:
Insert the ignition key in the ignition switch and turn
it to the “ ” position (the key can not remove).
Rotate the key clockwise to the “ ” position and
open the fuel fill cap (1).
Do not overfill the tank. There should be no fuel in
the filler neck (2).
After refueling, be sure to lock the fuel fill cap firmly.
(1)
(2)
30

KYMCO DINK 125 Specifications

General

Displacement	124.6 cc
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70-12
Rear Tire	130/70-12
Width	730 mm
Seat Height	780 mm
Cooling System	Air-cooled
Transmission	Automatic CVT
Starter	Electric
