CENTER COMPARTMENT/CENTER COMPARTMENT LIGHT
(page 32)
MAXIMUM WEIGHT LIMIT: 10kg (22 lbs)
The center compartment (1) is below the seat.
Opening and closing:See "SEAT" .
The center compartment light (2) will be turned ON automatically when the seat is opened.
Kept ON as long as the seat is opened regardless of the position of the ignitino switch.
Never exceed the maximum weight limit;
handling and stability may be severely affected.
The center compartment may become heated by
the engine. Do not store food and other articles
which are flammable or susceptible to heat
damage in this compartment.
Do not direct water under pressure against the
center compartment as water will be forced into
the compartment.
CAUTION
33
(2)
(1)
