KYMCO DINK 125 User Manual

Fuse box :
10A (red), 15A (blue), 20A
(yellow)
(see page 32)
(see page 78)
The fuse box is located under the battery in the battery
box .
The specified fuses (2) are:
1. Open the seat .
2. Open the battery cover. .
3. Open the fuse box cover (1).
4. Pull out the old fuse and install a new fuse. The spare
fuse (3) are located in the battery retainer.
5. Close the fuse box covers and seat.
(2)
81
(1)
(3)

KYMCO DINK 125 Specifications

General

Displacement	124.6 cc
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70-12
Rear Tire	130/70-12
Width	730 mm
Seat Height	780 mm
Cooling System	Air-cooled
Transmission	Automatic CVT
Starter	Electric
