10. A.C. GENERATOR/STARTER CLUTCH
10-8
Downtown 300i ABS
Install the starter idle gear and shaft.
Install the starter driven gear onto the
crankshaft.
FLYWHEEL INSTALLATION
Install the flywheel onto the crankshaft by
aligning the key on the crankshaft with the
groove in the flywheel.
Install washer and nut.
Hold the flywheel with the flywheel holder
and tighten the flywheel nut.
Torque: 5.5~6.5 kgf-m (58.8 N-m)
Remove the flywheel nut and washer.
Flywheel holder E021
Fl
y
wheel
Ke
y
• Before installation, check and make
sure that the inside of the flywheel is
not contaminated.
＊
Special
Shaft
Starter Driven Gea
r
Starter Idle Gea
r
Flywheel
Nut
Fl
y
wheel Holde
r
