3. INSPECTION/ADJUSTMENT
3-9
Downtown 300i ABS
BRAKE SYSTEM
There is adjuster on each brake lever.Each
adjuster has four positions so that the
released lever position can be adjusted to suit
the rider’s hands.
To adjust the distance of the lever from the
handlebar grip,push the lever(1) forward and
turn the adjuster knob(2) to align the number
with the arrow mark(3) on the lever holder.
BRAKE DISK/BRAKE PAD
Check the brake disk surface for scratches,
unevenness or abnormal wear.
Check if the brake disk runout is within the
specified service limit.
Check if the brake pad wear exceeds the
wear indicator line.
BRAKE FLUID
Turn the steering handlebar upright and
check if both brake fluid levels is at the upper
limit. If the brake fluid is insufficient, fill to the
upper limit.
Specified Brake Fluid: DOT-4
Keep grease or oil off the brake disk to
avoid brake failure.
＊
The brake fluid level will decrease if the
brake pads are worn.
＊
