14. K-XCT 125 i FUEL SYSTEM (Auto Control Fuel Injection System)
14-1
SYSTEM DIAGRAM
進氣壓力及
大氣壓力感
知器
曲軸感知器
感知器
含氧(O2)
感知器
CPS T-MAP TPS WTS O2
Voltage
進氣壓力及大氣壓力
感知器
感知器
INJECTOR
ABV
KEY OFF
INDUCTIVE
IGNITION COIL
ECU
FUEL PUMP
KEY ON
曲軸感知器
ROLL
