6.3 Adjusting the tiller angle
Always adjust the tiller so that you can
reach all displays and controls easily at any
time. The tiller can be variably adjusted.
adjusting the tiller
Turn and loose the locking knob(1)
Push the tiller forwards or backwards
into the required position (2).
Tighten the locking knob .
Ensure that the tiller is engaged
properly by moving slightly forwards
and backwards.
Accident hazard due to
non-engaged tiller!
• Ensure that the tiller
is
properly
engaged
after adjustment by
pushing
it slightly forwards and
then backwards.
NOTE:
The locking knob must be fully
tightened.
Adjusting the handle
Adjus
ting t
he handle:
Pull the tube (3) and turn knob
tight (4).
(2)
(1)
(3)
(4)
