Thi
ngs t
o know
12.5 The drive unit
The complete drive unit is located in the
rear of the
scooter and consists of the
fo
llowing main components:
• the battery case (3)
• the drive motor with rear axle (4)
Drive unit
12.6 The working principle
The drive consists of the drive motor, the
gearbox and the rear axle.
Drive takes place from the drive motor via
the gearbox and rear axle to the rear
wheels .
44
