THROTTLE LEVER ADJUSTMENT
Adjust the engine idling speed before
adjusting the throttle lever free play.
To adjust throttle free play (MXU 300/250):
1. Slide the rubber sleeve (1) back to expose
the throttle cable adjuster.
2. Loosen the lock nut (3), then turn the
adjuster (2) to obtain the correct free play.
(3~5 mm or 0.12~0.2 in)
3. Tighten the locknut and reinstall the sleeve.
Other checks:
Check the throttle cable for kinks and signs of
wear that could cause stretching or failure.
Lubricate the throttle cable with a
commercially available lubricant to prevent
premature wear and corrosion.
NOTE:
(1) Rubber sleeve (2) Cable a
(3
(A) 3~5 mm (0.12~0.2 in)
djuster
) Locknut (4) Throttle lever
(1)
(2) (3)
(4)
(A)
