41
POTENTIAL HAZARD
Improper use of the parking brake.
WHAT CAN HAPPEN
The ATV could start moving unexpectedly
if the parking brake is not applied before
starting the engine. This could cause loss
of control or a collision.
The brake could overheat if you ride the
ATV without releasing the parking brake.
You could lose braking performance which
could cause an accident. You could also
wear out the brakes prematurely.
HOW TO AVOID THE HAZARD
Always set the parking brake before
starting the engine.
Always be sure you have released the
parking brake before you begin to ride.
WARNING
DRIVE SELECT LEVER
The drive select lever is used for driving the
machine either forward or in reverse. Refer to
page 52 ~ 56 and 71 ~ 73 for drive select lever
adjustment and operation.
(1) Drive select lever
(R) For reverse drive
(N) Neutral
(F) For forward drive
MXU 250/150
(1)
(R)
(N)
(F)
