KYMCO MXU 150 User Manual

INSTRUMENTS AND INDICATOR
(1) Multi-function display
The display includes the following functions:
Speedometer
Odometer/Tripmeter
Digital clock
Coolant temperature gauge (MXU 300/250)
Fuel gauge
(2) High beam indicator
The ignition switch is at the " " position, the
high beam indicator lamp will light when the
headlight switch to select high beam ( )
(3) Low gear indicator (MXU 300)
The low gear indicator will light when the
transmission is in low gear and the ignition
switch is ON
.
.
The headlight can be turned on only when the
.engine is running
NOTE:
21
L
(1) Multi-function display
(2) High beam indicator
(3) Low gear indicator (MXU 300)
(4) Neutral indicator
(5) Reverse indicator
(6) Mode/Adjust button (A)
(7) Mode/Adjust button (B)
(1)
(2)
(4)
(5)
(6)
(7)
(3)
