1. GENERAL INFORMATION
1-4
ATV 50
Model No. LB10
Name MXU 50 REVERSE
Overall length 1786 mm (71 in)
Overall width 958 mm (38 in)
Overall height 1010 mm (40 in)
Wheel base 1105 mm (44 in)
Engine type Air cooled 2-stroke
Displacement 49.4 cm
3
(2.964 cu-in)
Fuel Used
92# nonleaded
gasoline
Front wheel 78 kg (171.6 lbs)
Dry weight Rear wheel 80 kg (176 lbs)
Total 158 kg (347.6 lbs)
Front wheel 83 kg (182.6 lbs)
Curb weight Rear wheel 84 kg (184.8 lbs)
Total 167 kg (36734 lbs)
Front wheel 21*7-10
Tires
Rear wheel 22*10-10
Ground clearance 162 mm (6.6 in)
Min. turning radius 2900 mm (116 in)
Starting system
Starting motor &
kick starter
Type Air cooled 2-stroke
Cylinder arrangement Single cylinder
Combustion chamber typ
－
Idle speed (rpm) 1800
Lubrication type Separate type
Oil pump type Plunger type
Oil filter type Full-flow filtration
Air cleaner type Sponge
Fuel capacity 8.1 liters
Type PB
Main jet No. 80
Venturi dia φ14 mm (φ0.56 in)
Throttle type Valve piston
Type CDI
Ignition timing 13.5°/1500 rpm
Spark plug NGK-BR8HAS
Spark plug gap 0.6～0.7mm
Battery Capacity 12V8AH
Clutch Type CVT
Operation
Automatic centrifugal
Type
Primary reduction
system
Helical gear/spur gear
Secondary reduction
system
Chain drive
Primary reduction ratio 1.2 – 3.5
Secondary reduction
ratio
20.12
Reverse ratio 46.11
Front Caster angle －
Axle Trail length －
Front 0.28 kgf/cm
2
(28 kPa, 4
psi)
Tire pressure
Rear 0.28 kgf/cm
2
(28 kPa, 4
psi)
Turning Left 40°
angle Right 40°
Brake system Rear Disk brake
type Front Drum brake
Suspension Front Swing
type Rear Swing arm
Shock
