KYMCO UXV500 User Manual

25
Indicates a potential hazard that could
result in serious injury or death.
PREVENTION
TIRES AND WHEELSTIRES AND WHEELS
TIRES AND WHEELSTIRES AND WHEELS
TIRES AND WHEELS
Correct tire pressure is crucial to the proper operation of your
UXV500. Consult the values listed below or the SPECIFICATIONS
section of this manual for tire pressure guidelines. Incorrect tire
pressure can cause poor handling, instability, and could cause
you to lose control of your vehicle.
A.A.
A.A.
A.
Br Br
Br Br
Br
akak
akak
ak
eses
eses
es
Press down on the UXV500’s brake pedal. If the pedal does not
feel firm, or if it feels soft or "weak," the brake system could be low
on fluid or have a leak. Is so, refer to the GENERAL MAINTE-
NANCE section of this manual for instructions. Do not use your
UXV500 unless the brakes are operating normally.
Test the parking brake to confirm that it locks the wheels into po-
sition, then disengage it to release the brake. The brakes on your
Side-by-Side vehicle are essential for safety and could fail if they
are not maintained properly.
Check:
1. Forward
2. Neutral
3. Reverse
Check:
1. Brake pedal
2. Parking brake
Check:
1. Free, smooth range of motion
2. The pedal returns after it is released
BB
BB
B
..
..
.
AccelerAcceler
AccelerAcceler
Acceler
aa
aa
a
tortor
tortor
tor
Your UXV500’s accelerator pedal should have a free, smooth range
of motion. If it seems to "stick" at any point, or does not return
when released, refer to the GENERAL MAINTENANCE section
of this manual for instructions. Driving your UXV500 with a stick-
ing accelerator can cause you to lose control of your vehicle and
may cause an accident. Do not drive your UXV500 if the accel-
erator action is not smooth and the pedal does not return after it is
released.
Front wheel air pressure: 10 psi (0.7 kgf/cm²)
Rear wheel air pressure: 14 psi (0.98 kgf/cm²)
CONTRCONTR
CONTRCONTR
CONTR
OLSOLS
OLSOLS
OLS
AND CABLESAND CABLES
AND CABLESAND CABLES
AND CABLES
With your vehicle’s engine running and parking brake applied, check
the transmission operation by shifting into each drive mode: for-
ward, neutral, and reverse. After testing, shift back into neutral and
turn the engine off before exiting the vehicle.
Check:
1 . Tire pressure
2 . Tire surface (tread and sidewall)
While checking your UXV500's tire pressure, inspect the tread
and the sidewalls of the tires for cracks, cuts, or other damage.
Immediately replace any tire that is damaged..
