67
Any oil used in place of the KYMCO recommended
engine oil can cause serious engine damage.
GENERAL MAINTENANCE
5. Remove the oil filter cartridge 5 with a suitable oil filter wrench.
Rotate the oil filter cartridge counterclockwise to remove it
from the engine.
NOTE: Skip step 5 and proceed to step 7 if you are not
going to replace the oil filter cartridge.
6. Lubricate the new oil filter cartridge’s o-ring gasket with clean
engine oil and install the filter on the engine. Tighten the oil
filter cartridge by rotating it clockwise unit it securely seats to
the engine
7. Reinstall the oil strainer and its component parts. Tighten the
oil strainer cap securely
8. Reinstall the oil drain plug and tighten it securely
9. Add the appropriate amount of engine oil
55
55
5
OIL QUANTITY
Without oil filter ................... 3.18 US qt, (3.0 L)
With oil filter change ........... 3.82 US qt, (3.6 L)
NOTE: The UTV should be parked on level ground, with
the engine off, when checking the engine oil level. Wait
approximately one minute after running for the oil level
to stabilize before checking.
77
77
7
77
77
7
Do not overfill the engine with oil. Overfilling the en-
gine can cause oil leaks and/or oil contamination of
the air filter element. Always make sure the oil level is
above the "L" mark but not higher than the "H" mark.
10. Warm up the engine for several minutes, then turn it off
11. Check the oil level at the inspection window
12. The oil level in the window 6 should be above the "L" mark
but not higher than the "H" mark. Add oil through the filler
cap 7 as required
NOTE: Dispose of the used oil and filter in an environ-
mentally proper way.
