11. CRANKCASE/CRANKSHAFT
11
13
VITALITY 50
CRANKCASE/BALANCER
INSTALLATION
Install the cam chain into the left crankcase.
Install the dowel pins and a new gasket onto
the left crankcase.
Install the crankshaft into the left crankcase.
Install the right crankcase.
Tighten the crankcase attaching bolt.
Torque: 0.8~1.2kgf-m
Bolt
Place the right crankcase over the
crankshaft and onto the left crankcase.
When installing the crankshaft, be
careful not to damage the oil seal.
