12. CARBURETOR
12
6
VITALITY 50
Remove the jet needle by removing the
needle clip.
Check the jet needle and throttle valve for
wear or damage.
THROTTLE VALVE INSTALLATION
Install the jet needle on the throttle valve
and secure with the needle clip.
Install the rubber seal on the throttle cable
and then install the carburetor top and
throttle valve spring.
Connect the throttle cable to the throttle
valve.
Carburetor
To
p
Throttle Valve
Rubber Seal
Throttle Cable
Throttle Valve Spring
Needle Retainer
2nd Notch (STD)
Throttle Valve
Jet Needle
Needle Clip
