Kyocera FS-4100DN User Manual

Document Box
5-24
Job Box
IMPORTANT To use the Job Box, an optional SSD (HD-6) or SD/SDHC memory card must be installed in the printer. The
RAM disk may also be used in the Proof-and-Hold and Private Print modes.
Job Box is a print function that makes the Job Retention function possible. The settings are specified from the printer driver.
Refer to Computer settings (Printer driver) on page 5-34 or the Printer Driver User Guide.
Job Retention
Job Retention has four modes as summarized below. These modes are selected from the printer driver through the
application software:
Note When using the RAM disk to use Job Box, set the RAM disk mode to On.
When using the SSD (HD-6) or an SD/SDHC memory card to use Job Box, set the RAM disk mode to Off. For details,
refer to RAM Disk Setting (Using the RAM disk) on page 4-81.
Quick Copy Proof-and-Hold Private Print Stored Job
Primary function To later print
additional copies
To proof the first copy
before printing
multiple copies
To hold the document
in printer to prevent
unauthorized access
To electronically store
documents such as
fax cover pages
Start storing by Printer driver Printer driver Printer driver Printer driver
On terminating print
setting from
application software
Prints simultaneously Prints one copy
simultaneously
Does not print Does not print
Retrieved by Operation panel Operation panel Operation panel Operation panel
Default number of
copies printed at
retrieval
Same as storing
(can be changed)
One less
(can be changed)
Same as storing
(can be changed)
One
(can be changed)
Maximum number of
jobs stored
†
†
Jobs in excess will cause the earlier ones to be deleted.
300 300 Depends on the SSD
or SD/SDHC memory
card capacity (the job
is automatically
deleted after printing)
Depends on the SSD
or SD/SDHC memory
card capacity
PIN security No No Yes Yes (if necessary)
Data after printing Stored Stored Deleted Stored
Data at power off Deleted Deleted Deleted Stored
SSD (HD-6) or SD/
SDHC memory card
Necessary Unnecessary
(RAM disk may also
be used)
Unnecessary
(RAM disk may also
be used)
Necessary
Note Refer to the Printer Driver User Guide for the driver settings and print (save) procedures.

Kyocera FS-4100DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Mobile printing technologies	-
PCL fonts	93
Printer fonts	Bitmap, PCL, PostScript
Maximum duty cycle	200.000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, PCL 5c, PCL 6, PDF 1.7, PostScript 3
Processor model	465
Processor family	PowerPC
Maximum internal memory	1280 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Total input capacity	600 sheets
Total output capacity	500 sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet, Parallel, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	13.3 W
Power consumption (printing)	618 W
Power consumption (PowerSave)	1.6 W
Display	LCD
Certification	GS, TÜV, CE
Product color	Black, White
Media thickness	0.11 mm
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	320 mm
Dimensions (WxDxH)	380 x 416 x 320 mm
