Kyocera FS-4100DN User Manual

A-15
Appendix
Selecting the Right Paper
This section describes the guidelines for selecting paper.
Condition
Avoid using paper that is bent at the edges, curled, dirty, torn, embossed, or contaminated with lint, clay, or paper shreds.
Use of paper in these conditions can lead to illegible printing and paper jams, and can shorten the life of the machine. In
particular, avoid using paper with a surface coating or other surface treatment. Paper should have as smooth and even a
surface as possible.
Composition
Do not use paper that has been coated or surface-treated and contains plastic or carbon. The heat of fusing can cause such
paper to give off harmful fumes.
Bond paper should contain at least 80 % pulp. Not more than 20 % of the total paper content should consist of cotton or
other fibers.
Paper Sizes
Cassettes and the MP tray are available for the paper sizes listed in the table below. For details, including the paper sizes
for the paper feeder (Optional paper feeder PF-320) refer to Setting the standard paper size on page 4-28.
The dimensional tolerances are ±0.7 mm (±0.0276 inches) for the length and width. The angle at the corners must be 90°
±0.2°.
Yes: Can be stored No: Cannot be stored
Paper Size Size
Cassette
(FS-2100D/
FS-2100DN)
Cassette
(FS-4100DN/
FS-4200DN/
FS-4300DN)
Cassette
(PF-320)
Bulk Paper
Feeder
(PF-315+)
MP Tray
Envelope Monarch 3.88 × 7.5 inches No No Yes Yes Yes
Envelope #10 4.13 × 9.5 inches No No Yes Yes Yes
Envelope DL 110 × 220 mm No Yes Yes Yes Yes
Envelope C5 162 × 229 mm Yes Yes Yes Yes Yes
Executive 7.25 × 10.5 inches Yes Yes Yes Yes Yes
Letter 8.5 × 11 inches Yes Yes Yes Yes Yes
Legal 8.5 × 14 inches Yes Yes Yes No Yes
A4 210 × 297 mm Yes Yes Yes Yes Yes
B5(JIS) 182 × 257 mm Yes Yes Yes Yes Yes
A5 148 × 210 mm Yes Yes Yes Yes Yes
A6 105 × 148 mm No Yes No Yes
†
Yes
B6 128 × 182 mm No Yes Yes Yes Yes
Envelope #9 3.88 × 8.88 inches No No Yes Yes Yes
Envelope #6-3/4 3.63 × 6.5 inches No No Yes Yes
†
Yes
ISO B5 176 × 250 mm Yes Yes Yes Yes Yes
Hagaki 100 × 148 mm No No No Yes
†
Yes
OufukuHagaki 148 × 200 mm No Yes Yes Yes Yes
Oficio II 8.5 × 13 inches Yes Yes Yes No Yes

Kyocera FS-4100DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Mobile printing technologies	-
PCL fonts	93
Printer fonts	Bitmap, PCL, PostScript
Maximum duty cycle	200.000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, PCL 5c, PCL 6, PDF 1.7, PostScript 3
Processor model	465
Processor family	PowerPC
Maximum internal memory	1280 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Total input capacity	600 sheets
Total output capacity	500 sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet, Parallel, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	13.3 W
Power consumption (printing)	618 W
Power consumption (PowerSave)	1.6 W
Display	LCD
Certification	GS, TÜV, CE
Product color	Black, White
Media thickness	0.11 mm
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	320 mm
Dimensions (WxDxH)	380 x 416 x 320 mm
