Operator's Manual – Stacker Vendor
©
LAI GAMES
Page 40
LAMPS
COIN DOOR LAMPS
The coin door lamps all are 12V/DC GE192 or equivalent and can be accessed
through the coin door.
BUTTON LAMPS
The button lamps all are 12V/DC GE192 or equivalent and can be accessed
through the coin door or back door.
HEADER LAMPS
There is one standard FL 15 fluorescent tube for the Header Display. Access is by
the removing of the machine header cover and accessing the tube from the front.
PRIZE DISPLAY SIDE LAMPS
There are two standard FL 18 fluorescent tubes for side lighting the prize display.
Access is by the removing of the Lamp Brackets and accessing the tubes from the
back door.
PRIZE DISPLAY DOWN LAMPS
There are 2 x 12V 20W 36Dgr-halogen lamps mounted in the top of the prize
display. These are standard dichroic lamps and are accessed from the prize display
through the prize display door.
* WARNING! *
Always
turn OFF Mains power and unplugged the game, before replacing any
lamps.
Always allow time for cooling as Lamps that have been active for a time may still
be too hot to touch.
* CAUTION! *
Always
replace the lamps with the same or equivalent size, wattage and voltage.
