28
4 Design and Functions
4 Design and Functions
4.1 Design
Construction of pilot burner versions A and B
Connections: Gas and air supply
Connections: Measurement sockets
Connections: test sockets
Fig. 4-1 Main components of LAMTEC GFI pilot
burner
1 Outer tube
2 Air housing
3 Gas block
4 Connection enclosure
Fig. 4-2 Gas and air supply connections
1 Air supply connection
2 Gas supply connection
Fig. 4-3 Connections of the measurement sock-
ets for gas and air
1 Measurement socket - air
2 Measurement socket - gas
Fig. 4-4 Test socket connections
1 and 2 test sockets for the temporary
connection of a measurement device
for
flame setting
