30
5 Commissioning
5 Commissioning
5.1 Transport
NOTICE
Depending on the version, the device can be heavy and bulky.
The following regulations should be observed during transport:
Always transport the device in the original protective packaging.
Depending on the weight and situation, use lifting gear and/or obtain assistance from an-
other person
5.2 Assembly
Observe the safety regulations!
NOTICE
Fragile!
Isolators installed in the pilot burner are ceramic and may break.
Do not allow pilot burners to drop or suffer impact.
CAUTION!
Loose, unfastened pilot burner!
Risk of injury due to falling pilot burners.
Secure the pilot burner against falling for the duration of the assembly process by hand or
using a suitable device.
WARNING!
All activities described in this chapter must only be performed by qualified, authorised person-
nel observing all safety requirements.
Select mounting location
The mounting location must meet the following requirements:
• Space requirement for mounting and removal: See section "Space requirement for mount-
ing and removal".
• Remaining clearance after mounting: See section "Remaining clearance after mounting".
• Ambient conditions: For more details, see chapter 3.6 Technical Data
• The mounting surface must be torsion-resistant, stable and even.
• Distance to external components and to the system control: For more details, see chapter
3.6.1 Technical data for the GFI 48 pilot burner
