Puridest
Distillation Apparatus
15
/
30
Distillation Apparatus Puridest models PD 8 R, PD 12 R 11.2
PD 8 R PD 12 R
Exterior dimensions (W x D x H) 780 mm x 405 mm x 575 mm 780 mm x 405 mm x 705 mm
Storage tank 16 litres distillate 24 litres distillate
Distillation capacity 8 l / h distillate 12 l / h distillate
Distillate quality Mono distillate
approx. 2.3 µS / cm at 25 °C in conformity with
DAB, bacteria and pyrogen free, low gas content
Mono distillate
approx. 2.3 µS / cm at 25 °C in conformity with
DAB, bacteria and pyrogen free, low gas content
The conductivity of the distilled water is directly related to the chemical composition of the raw water. Components of the raw water having the same or a
lower evaporation point than water may deteriorate the conductivity.
Cooling water requirement 72 l / h 198 l / h
Low water cut-off Electromechanical temperature limiter, with capillary
tube sensor.
Switch-off temperature 135 °C / -15 K
Electromechanical temperature limiter, with capil-
lary tube sensor.
Switch-off temperature 135 °C / -15 K
Water pressure min. / max. > 3 bar / 7 bar
> 43.5 psi / 101.5 psi
> 3 bar / 7 bar
> 43.5 psi / 101.5 psi
Electrical connection
Mains supply
On-site fuse
230 V +/-10 %, 50 / 60 Hz, 6.0 kW
Connection box for permanent connection to the
mains Netzsicherung / on-site-fuse 35 Amp.
220 V / 3 ~ / PE +/-10 %, 50 / 60 Hz, 9.0 kW
Mains connection cable for permanent connection
to the mains / on-site-fuse 3 x 25 Amp.
220 V / 3 ~ / PE +/-10 %, 50 / 60 Hz, 6.0 kW
Mains connection cable for permanent connection
to the mains / on-site-fuse 3 x 16 Amp.
400 V / 3 ~ / N / PE +/-10 %, 50 / 60 Hz, 9.0 kW
Mains connection cable for permanent connection
to the mains / on-site-fuse 3 x 16 Amp.
400 V / 3 ~ / N / PE +/-10 %, 50 / 60 Hz, 6.0 kW
Mains connection cable for permanent connection
to the mains / on-site-fuse 3 x 16 Amp.
Caution! Mains voltage deviations, even with the mentioned limits, influence the quantity of distillate produced.
Protection class / - type I / IP20 I / IP20
Surrounding conditions Use only inside buildings (not in potentially explosive
areas).
Use only inside buildings (not in potentially explosive
areas).
Height above MSL up to 2000 m MSL up to 2000 m MSL
Ambient temperature +10 °C to +40 °C +10 °C to +40 °C
Humidity max. 80 % rel. humidity to 31 °C, decreasing to 40
% rel. humidity at 40 °C
max. 80 % rel. humidity to 31 °C, decreasing to 40
% rel. humidity at 40 °C
Net Weight 35.8 kg 40.9 kg
Weight with water filling 56.5 kg 70.4 kg
