Lauda PD 2 R User Manual

24 / 30 Puridest Distillation Apparatus 09/2020
14 List of spare parts
Pos. No. Part-No. Article
1 0025517 Lid pin
0025437 Securing ring
2 A000077 Heating element 1500 W / 230 V (for PD 2 R)
A000084 Heating element 2000 W / 230 V (for PD 8 R)
A000085 Heating element 3000 W / 230 V (for PD 4 R / PD 12 R)
3 A000096 Electronic level switch
4 A000092 Low water cut-off
5 A000124 Mains connection cable (for PD 2 R / PD 4 R)
0030029 Mains connection cable (for PD 8 R / PD 12 R – 400 V / 3 ~ / N / PE)
0030067 Mains connection cable (for PD 8 R / PD 12 R – 230 V / 3 ~ / PE)
5.1 A000125 Fuse holder, 2-pole (for PD 2 R / PD 4 R)
5.2 A000126 Mains fuse 8 Amp. inert (for PD 2 R)
0012092 Mains fuse 15 Amp. inert (for PD 4 R)
6 A000091 Contactor
7 0014325 Stand
8 A000127 Main switch
9 0012635 LED pilot lamp, red
10 92002019 Dust guard shield
11 0017427 Profiled silicon sealing
12 0016214 Cooling coil (for PD 2 R)
A000110 Cooling coil (for PD 4 R)
A000111 Cooling coil (for PD 8 R)
0016205 Cooling coil (for PD 12 R)
0025232 Nut
0017339 Seal
13 0015115 Hose spout for cooling water outlet
0015116 Nut
0017316 Seal
14 A000090 Solenoid valve
A000106 Quantity regulator 0.5 l / min (for PD 2 R)
A000107 Quantity regulator 0.8 l / min (for PD 4 R)
A000109 Quantity regulator 1.3 l / min (for PD 8 R)
A000105 Quantity regulator 3.3 l / min (for PD 12 R)
15 0015112 Screw connection
16 A000115 Hose tap ¼ “
0015511 Hexagon bushing ¼ “
0015101 Hose spout ¼ “
0017309 Seal
17 A000102 Distillate outlet tap
18 0012636 LED pilot lamp, yellow
DOMINIQUE DUTSCHER SAS
