13 Connection to the Mains
The electrical connection must ensure an all-pole separation from the mains supply. Installed assembly parts, such as
shock-proof sockets or main switches, must be installed so as to ensure clear identification and they must be within easy
reach in an emergency case. Distillation Apparatus models PD 8 R and PD 12 R must have a permanent connection with
the mains. This may only be implemented through an on-site main switch or through a CEE plug in conformity with IEC
standard 60309-2 (see examples for connection to the mains in chapter 13.1).
Colour decoding of the individual leads of the mains connection cables for models PD 8 R and PD 12 R:
Colour decoding Mains supply
2
2
0
V / 3
~
/ PE 50 / 60 Hz
Mains supply
400
V / 3
~
/
N /
PE
50 / 60
Hz
ge/gr
–
gelb/grün
PE (
Protective earth
)
PE (
Protective earth
)
bl
–
blue
N
sw
–
black
L1
L1
br
–
brown
L2
L2
gra
–
grey
L3
L3
Distillation Apparatuses can be supplied in different versions for connection to different mains supplies.
Models PD 2 R and PD 4 R for connection to 230 V (see nameplate) can be connected to all mains supplies with 220 V
or 230 V.
Models PD 8 R and PD 12 R for connection to 220 V / 3 ~ (see nameplate) can only be connected to mains supplies
with 220 V / 3. ~ / PE.
Models PD 8 R and PD 12 R for connection to 400 V / 3 ~ (see nameplate) can only be connected to mains supplies
with 400 V / 3. ~ / N / PE.
Electrical fuses
Model
Power
Power consumption at mains voltage
*
Mains fuse (F2
–
F4)
PD 2
R
1.
5 kW
6.
5 A
at
230 V
1
0
Amp
PD 4
R
3
.
0
kW
13.
0 A
at
230
V
16
Amp
PD 8 R 6.0 kW
6.0 kW
6.0 kW
26.1 A at 230 V
15.8 A at 220 V / 3 ~ / PE
8.7 A at 400 V / 3 ~ / N / PE
35 Amp
16 Amp
10 Amp
PD 12 R 9.0 kW
9.0 kW
23.6 A at 230 V / 3 ~ / PE
13.0 A at 400 V / 3 ~ / N / PE
25 Amp
16 Amp
* see nameplate
