Leica T-Scan 5 - T-Scan Holder and Controller Front View

Colour Pattern Status information
Green Static Computer software has connected to T‑Scan
controller.
2.4.2 T‑Scan holder
Use the horizontal scanner holder (a) as a safe storage place for the T‑Scan
sensor.
015904_001
a
a Horizontal scanner holder
2.4.3 T‑Scan controller
The T‑Scan controller is the control unit for the T‑Scan sensor. This device
controls the scan frequencies, records the measurement data and synchroni-
ses the scan data with the 6DOF measurements of the Absolute Tracker.
Front view
a
015306_001
a Power switch
Horizontal scanner
holder
Control unit for
T‑Scan sensor
