LEM SWING16 User Manual

16
Technical specifications
SECTION LEVELS & DATA CONNECTORS
MONO INPUT CHANNEL
sensitivity
from -10 to -60dB
impedance
1.3 kOhms
sensitivity
from +10 to -40dB
impedance
10 kOhms
HPF
75Hz, 18dB/oct.
HIGH
±15dB @ 12kHz, SHELVING
HI-MID
±12dB @ 3kHz, PEAKING
LO-MID
±12dB @ 800Hz, PEAKING
LOW
±15dB @ 80Hz, SHELVING
STEREO INPUT CHANNEL
sensitivity
+4dB
impedance
10 kOhms
sensitivity
-50dB
impedance
1.3 kOhms
HIGH
±15dB @ 12kHz, SHELVING
MID
±12dB @ 2.5kHz, PEAKING
LOW
±15dB @ 80Hz, SHELVING
MASTER SECTION
MIX output (balanced)
output level
+4dB /-26dB Balanced XLR-M
MIX output (unbalanced)
output level
+4dB Unbalanced JACK
MIX B output
output level
+4dB RCA phono
CONTROL ROOM output
output level
+4dB Unbalanced JACK
MONITOR output
output level
+4dB Unbalanced JACK
AUX sends
output level
+4dB Unbalanced JACK
AUX return
sensitivity
-10dB Unbalanced JACK
IN
-10dB
OUT
+4dB
inimum impedance
200 Ohms
output level
2x160mW
GENERAL SPECIFICATIONS
Frequency response 20Hz - 60kHz, ±1dB
Hum & Noise -90dB
THD <0.005% @ 1kHz
IMD <0.005% @ 1kHz
Crosstalk
FADER
MUTE
PAN
-85dB
-84dB
-85dB
Maximum levels
MIC IN
TAPE IN
other outputs
MIX OUT (XLR)
other outputs
+14dBu
+16dBu
+22dBu
+28dBu
+22dBu
Power supply see label on the apparatus
Weight
kg
4.5
Dimensions
mm (WxHxD)
305x72x354
MIC input (ch 5/6)
EQ
EQ
Balanced JACK
Balanced XLR-F
SWING 12 • TECHNICAL SPECIFICATIONS
TAPE RCA phono
HEADPHONES output Stereo JACK
MIC input Balanced XLR-F
LINE input Balanced JACK
STEREO LINE input
