Logical
@ (hexa) @ (deci)
WA LC DS50
01H 1
R/W L [On/Off] Unit √ √ 3111
02H 2
R/W L [Reset] Discharges the safety measures of the unit √ √ 3113
03H 3
R/W L
not used
04H 4
R/W L
not used
05H 5
R/W L
[BMS] Activation of the Inoccupation mode [Off] occupation mode - [On] inoccupation
mode
√ √ 3935
06H 6
R/W L
not used
07H 7
R/W L
not used
08H 8
R/W L
not used
09H 9
R/W L
not used
0AH 10
R/W L
not used
0BH 11
R/W L
not used
0CH 12
R/W L
not used
0DH 13
R/W L
not used
0EH 14
R/W L
not used
0FH 15
R/W L
not used
10H 16
R/W L [Clock] [OFF] read hour & minute [ON] write hour & minute √ √ …
11H 17
R/W L
not used
12H 18
R/W L [Dry contact] Digital Output, Free 2, BE50-J5-NO1 √ √ 2171
13H 19
R/W L [Dry contact] Digital Output, Free 3, BE50-J6-NO2 √ √ 2172
14H 20
R/W L [Dry contact] Digital Output, Free 4, BE50-J7-NO3 √ √ 2173
15H 21
R/W L [Dry contact] Digital Output, Free 5, BE50-J8-NO4 √ √ 2174
16H 22
R/W L
not used
17H 23
R/W L
not used
18H 24
R/W L
not used
19H 25
R/W L
not used
1AH 26
R/W L
not used
1BH 27
R/W L
not used
1CH 28
R/W L
not used
1DH 29
R/W L
not used
1EH 30
R/W L
not used
1FH 31
R/W L
not used
20H 32
R/W L
not used
21H 33
R L [Alarm] General √ √ 1000
22H 34
R L [On/Off] Pump, 1 √ √ 2315
23H 35
R L [On/Off] Pump, 2 √ √ 2317
24H 36
R L [On/Off] Compressor 1, Circuit 1 √ √ 2416
25H 37
R L [On/Off] Compressor 2, Circuit 1 √ √ 2426
26H 38
R L [On/Off] Compressor 3, Circuit 1 (WA) or Compressor 1, Circuit 3 (LC) √ √ 2436
27H 39
R L [On/Off] Compressor, Heat pump, Circuit 1 √ 2417
28H 40
R L [On/Off] Compressor 1, Circuit 2 √ √ 2446
29H 41
R L [On/Off] Compressor 2, Circuit 2 √ √ 2456
2AH 42
R L [On/Off] Compressor 3, Circuit 2 (WA) or Compressor 1, Circuit 4 (LC) √ √ 2466
