11
Figure 21
Do not attempt repair of this unit unless you are
familiar with the necessary tools, equipment,
utility connections and potential hazards.
Service should be performed only by a qualified
technician.
Failure to do so could result in reduced perfor-
mance of the unit, serious personal injury or
death.
This guide contains service checks to assist service
personnel in locating and correcting any malfunction that
might occur to render the air cleaner ineffective or inop-
erative. The air cleaner has been designed with replace-
able components, such as the high-voltage power supply
and air flow switch. This allows the serviceman to replace
a faulty component rather than attempt repairs of such
components in the field.
All voltage measurements indicated can be made with a
high voltage D.C. probe and a general purpose volt ohm
meter. For example: Simpson 260 or equivalent.
For test purposes, the air flow switch may be “wired out”
of the system. This will eliminate the need for air flow
across the sensing thermistor to energize the power
supply (see Fig 22).
NOTE: All tests to be performed with the Ozone Reduc-
tion Jumper intact.
NOTE: When servicing the power pack components, all
wiring must be routed to factory specifications.
The solid-state power supply is not
designed for individual component part
replacement and must be replaced as
a complete "snap-in" unit.
Input voltage: 120 VAC 60 Hz.
Output to light: 1.5 to 2.5 VDC
H.V. Output: 6450 VDC (nom)
Collecting Cell
Specifications
Power Supply
Specifications
1400 cfm - 1.2 Ma @ 6450 VDC
1600 cfm - 1.5 Ma @ 6450 VDC
2000 cfm - 1.7 Ma @ 6450 VDC
Operating
Light
Power
Supply
Cell Contact
& Insulator
ON/OFF
Switch
Cover Assembly
AirFlow Switch
Power Pack
Assembly
L1
120 VAC
Connector
Wht
Wht
Gnd
Red
Blk
Blk
Wht/Brn
Wht
Blk
Blu
Wht/Brn
Wht
Blk
Blu
L2
Service
▲
!
WARNING
To Next Page
