9
Rated Capacity 1400 cfm 1600 cfm 2000 cfm
Max. Pressure Drop .08 in. W.G. .12 in. W.G. .09 in. W.G.
Cell Weight (2) 9 lbs. each (2) 9 lbs. each (2) 11 lbs. each
Power Pack Weight 8 lbs. 10 lbs. 10 lbs.
Unit Weight 43 lbs. 44 lbs. 52 lbs.
Power Consumption 40 Watts (Max) 40 Watts 40 Watts
Electrical Input 120 VAC 60 hz. 120 VAC 60 hz. 120 VAC 60 hz.
Electrical Output 1.2 Ma 1.5 Ma 1.7 Ma
@ 6450 VDC (nom)
Max. Ozone Generation 37 ug/min 37 ug/min 37 ug/min
Temperature Rating 40˚F to 125˚F40˚F to 125˚F40˚F to 125˚F
EAC-14 EAC-16 EAC-20
AIR CLEANER MODEL NUMBER
SPECIFICATIONS
Specifications
