31
LABEL ALL WIRES PRIOR TO DISCONNECTION
WHEN SERVICING CONTROLS. WIRING ERRORS
CAN CAUSE IMPROPER AND DANGEROUS OPERA-
TION. VERIFY PROPER OPERATION AFTER SERVIC-
ING.
e thermostat location has an important eect on the op-
eration of your boiler system. BE SURE TO FOLLOW THE
INSTRUCTIONS INCLUDED WITH YOUR THERMOSTAT.
Locate the thermostat about ve feet above the oor on an
inside wall. It may be mounted directly on the wall or on a
vertical mounted outlet box. It should be sensing average room
temperature. Avoid the Following:
Set heat anticipator at 0.7 amps. Connect 24 Volt thermostat
leads to the two(2) yellow wires located in service switch junc-
tion box, located on outer jacket of boiler. See
Figure #13
for
service switch junction box and thermostat eld wiring con-
nections.
See
Figure #13
(following page) for service switch junction
box and circulator pump eld wiring connections. A 5 feet wir-
ing harness with exible metal conduit is supplied to connect
the circulator pump to the service switch junction box. If the
two 120 Volt circulator wire terminals inside the junction box
are not used, please leave the two wire nuts to prevent the short
circuit.
ings to Avoid when Locating ermostats
DEAD SPOTS:
Corners and alcoves Behind doors
COLD SPOTS: HOT SPOTS:
Concealed pipes or ducts
Concealed pipes
Fireplace
Stairwells - dras
TV sets
Radios
Unheated rooms on
other side of wall
Lamps
Direct sunlight
Kitchens
CAUTION
!
