Lennox MWCB Series Service Manual

44
9.3.3. MCB012S4S-1L, MHB009S4S-1L and MHB012S4S-1L
1. Disconnect the
compressor
connector and
remove the
grounding screw.
2. Pull out the wires from
electrical supporting
plate and turn over
the electronic control
assembly.
3. Remove the four
hooks to remove
the control box sub-
assembly.
4. Remove the two
hooks to remove the
xing board.
5. Disconnect the
connectors from the
electronic control
board.
6. Then remove the
four hooks securing
the electronic control
board(
